DISPLACEMENT ANALYSIS OF SHEET PILE WITH TIE BEAM ON BREAKWATER CONSTRUCTION BY USING PLAXIS

  • Maulana Arif Universitas Gadjah Mada

Abstract

The breakwater construction usually founded in coastal area with many public or company facilities. It is very useful to break the ocean waves so it can not reach the shore line. Furthermore, the breakwater construction is also applied as a barier for a port for ship docked. One of the type of breakwaters is tube column filled with compacted sand reinforced by sheet file and tie beam. This research will discuss about the sheet pile displacement in static and dynamic condition. Plaxis is applied as the main tool to built the 2-D model based on given data from field observation. The input parameter for this model is applied in soil stratigraphy, compacted sand column, sheet pile, tie beam, pseudostatic wave force, sea level and earthquake acceleration. The running of this model divided in three condition. There are static condition, static condition with pseudostatic wave force, and dynamic condition. The results show different displacement between the conditions. The sheet pile displacement in static condition is 3.35 cm at harbor side and 1.91 cm at open sea. The sheet pile displacement in static condition with pseudostatic wave force is 12.14 cm at harbor side and 12.08 cm at open sea. The sheet pile displacement in dynamic condition has 5 cm peak both harbor side and open sea.

Keywords: breakwater, sheet pile, displacement, plaxis

Downloads

Download data is not yet available.

References

Azizi, F., 2000. Applied Analysis In Geotechnics. E & FN Spon, London.
Bowles, J.E., 1977. Foundation Analysis and Design, McGraw-Hill Kogakusha Ltd, Tokyo.
Bowles, J.E., 1984. Physical and Geotechnical Properties of Soils, Second ed. McGraw-Hill, Auckland.
Brinkgreve, R.B.J., Al-Khoury, R., Bakker, K.J., Bonnier P.G., Brand, P.J.W., Broere, W., Burd, H.J., Soltys, G., Vermeer, P.A., Den Haag, DOC, 2002. Plaxis, A.A Balkema Publishers, Lisse.
Das, B. M., 2010. Principles of Geotechnical Engineering, Seventh ed. Cengange Learning, Stamford.
Kumar, R., Bhargava, K., Choudhury, D., 2016. Estimation of Engineering Properties of Soils from Filed SPT Using Random Number Generation, Indian National Academy of Engineering. Volume 1: 77-84.
Published
2020-06-29
How to Cite
Arif, M. (2020). DISPLACEMENT ANALYSIS OF SHEET PILE WITH TIE BEAM ON BREAKWATER CONSTRUCTION BY USING PLAXIS. FROPIL (Forum Profesional Teknik Sipil), 8(1), 1-8. https://doi.org/10.33019/fropil.v8i1.1700
