PENINGKATAN KUALITAS SERAT REKEL UNTUK BAHAN KOMPOSIT SEBAGAI BAHAN KOMPONEN KENDARAAN BERMOTOR

  • Herwandi Herwandi Politeknik Manufaktur Negeri Bangka Belitung
  • Robert Napitupulu Politeknik Manufaktur Negeri Bangka Belitung

Abstract

ABSTRACT



Research concerning rekel (resam and kelapa) fiber for composite material had been done by the author since 2013 until 2015. In 2015, The author had done test of a chemical with NaOH to resam fiber. Result showed that the composite met the standard car dashboard. Therefore, Study is conducted to see the effect of rekel fiber with NaOH. The purpose of research was to obtain new composite materials, the result of a chemical treatment with NaOH to rekel fiber. The stages of the process consist of making test samples, mechanical testing and data analysis. The materials for making the samples comprise of fiber, resin Yukalac 157 BQTN-EX, MEKPO as  a hardener, 5 % NaOH and Wax glasses. The size of the test sample was based on standard tensile test (ASTM D 638), flexure (ASTM D 790) and impact (ISO 179). The highest value of tensile was 24,4 MPa, elastic modulus 6686 MPa and a strain 0,38%. The maximum value of the flexure strain was 94,85 MPa and a flexural modulus 4141,5 MPa, while the highest value of  impact was 55,81 kJ/m2.  Based on the findings, it can be concluded that the results of test met the standard plastic used for car dashboard.

Keywords: Rekel fiber, composite, NaOH, tensile test, flexure test, impact test

Downloads

Download data is not yet available.

References

[1] Neng Sri Suharty, 2007, Rekayasa polimer menggantikan bahan tradisional, Pidato Pengukuhan guru besar kimia-Universitas Sebelas Maret.
[2] Basuki Widodo, 2008, Analisa sifat mekanik komposit epoksi dengan penguat serat pohon aren (ijuk) model lamina berorientasi sudut acak (random), Jurnal teknologi technoscientia.
[3] Muh Amin dan Samsudi R, 2010, Pemanfaatan limbah serat sabut kelapa sebagai bahan Pembuat helm pengendara kendaraan roda dua, Prosiding nasional unimus.
[4] Rajesh Ghosh, A. Rama Krishna , G. Reena , dan Bh.Lakshmipathi Raju, 2011, Effect of fibre volume fraction on the tensile strength of Banana fibre reinforced vinyl ester resin composite, International journal of advanced engineering sciences and technologies.
[5] Lawrence T. Drzal, 2007, Sustainable Bio-Based Structural Material: opportunities and challenges, Michigan State University.
[6] George J., Janardhan R., Anand, J.S., Bhagawan S.S., dan Thomas S. 1996. Melt Rheological Behavior Of Short Pineapple Fibre Reinforced Low Density Polyethylene Composites, Journal Of Polymer, Volume 37, No. 24, Gret Britain.
[7] Jefferjee B., Heyleys, dan Zylyon. 2003. Composite Aplication using Coir Fibres in Sri Lanka, Final report of fast track project from Common Fun for Commodities, Delft University of Technology, Netherlands.
[8] Prasad S. V., Pavithran, C., dan Rohatgi, P. K. 1983. Alkali treatment for coir fibres for coir-polyester composites, Research regional laboratory, India, pp. 1443-1454.
[9] Nayak S. K., Tripahy S.S., Rout, J., dan Mohanty, A.K. 2000. Coir-Polyester Composite: Effect on fibre surface treatment on mechanical properties of composite, International Plastics Engineering and Technology, Vol.04, pp.79-86.
[10] Herwandi, dan Robert Napitupulu, 2015. Pengaruh Peningkatan Kualitas Serat Resam Terhadap Kekuatan Tarik, Flexure Dan Impact Pada Matriks Polyester Sebagai Bahan Pembuatan Dashboard Mobil, Jurnal Sintek Jurusan Teknik Mesin 2015 di Universitas Muhammadiyah Jakarta.
Published
2017-07-03
How to Cite
Herwandi, H., & Napitupulu, R. (2017). PENINGKATAN KUALITAS SERAT REKEL UNTUK BAHAN KOMPOSIT SEBAGAI BAHAN KOMPONEN KENDARAAN BERMOTOR. Machine : Jurnal Teknik Mesin, 3(2), 9-15. Retrieved from https://journal.ubb.ac.id/index.php/machine/article/view/456
